Вентили и Инверторы

Логический элемент ИЛИ, 4 элемента, 2 входа, 8мА, 4.75В до 5.25В, SOIC-14.The SN74LS32D is a quad 2-input positive-OR Gate contains four independent circuits and operates at a supply voltage range of 4.75 to 5.25V. This device perform the Boolean function Y = A + B or Y = (A\ • B\)\ in positive logi..

Логический элемент ИЛИ, 4 элемента, 2 входа, 8мА, 4.75В до 5.25В, DIP-14.The SN74LS32N is a quad 2-input Positive-OR Gate characterized for operation from 0 to 70°C...

Буфер ИЛИ-НЕ, 4 элемента, 2 входа, 24мА, 4.75В до 5.25В, SOIC-14...

И-НЕ буфер, 4 элемента, 2 входа, 24мА, 4.75В до 5.25В, DIP-14...

И-НЕ буфер, 4 элемента, 2 входа, 24мА, 4.75В до 5.25В, SOIC-14.The SN74LS38D is a quad 2-input positive-NAND buffers with open collector outputs contains four independent circuits. The open-collector outputs require pull-up resistors to perform correctly. This device may be connected to other open-c..

И-НЕ буфер, 4 элемента, 2 входа, 24мА, 4.75В до 5.25В, DIP-14.The SN74LS38N is a quad 2-input positive-NAND buffers with open collector outputs contains four independent circuits. The open-collector outputs require pull-up resistors to perform correctly. This device may be connected to other open-co..

Логический элемент И / ИЛИ / инвертор, 2 входа, 8мА, 4.75В до 5.25В, SOIC-14...

Логический элемент исключающее ИЛИ, 2 входа, 4 элемента, 30нс, 4.75В до 5.25В, SOIC-14.The SN74LS86ADR is a quad 2-input exclusive-OR Gate contains four independent circuits. This device performs the Boolean function Y = A ? B or Y = A\B + AB\ in positive logic. A common application is as a true/com..
